BRAT 90 Quick-Start Reconfigurable Automatic Tester
BRAT 90 Features
- Leveraging PADS Technologies for Applying General Purpose Parallel Testing
- PXI/PXIe Chassis – 8 Slots with Cabled I/O Controller
- Mini ITX Motherboard 8th Generation or Better Intel CPU with Monitor, Full Keyboard, Detached Mouse
- 4 Fully Programmable DC Power Supplies; 32 V @ 5 A Each
- ODU-MAC Black Line Modular Contact Interface – Signal, Power, Coax
- Quick-Release Top Panel for Easy Maintenance Access
Other Quick-Start-Derived Testers
BRAT Bomber LRSO ATS Rack
ATS - Rack System (LRSO ATS Configuration)
BRAT TVS Tester
Transient Voltage Suppression (TVS) Tester - Standalone ruggedized test set with functionality to support automatic testing of avionic UUTs for transient Voltage Suppression. Includes Reconfigurable Tester, Transit Case, Interface Panel, Switch Matrix, DMM, and Single-Phase AC Power Supply.
Options Available for the BRAT 90
Option 90-02
BRAT 90 Quick-Start Option 02 - Package the Quick-Start Test System in a Ruggedized 19-Inch Rack-and-Stack Equipment Transit Case.
Option 90-03
BRAT 90 Quick-Start Option 03 - Configure the Quick-Start Test System with the ATTI MIL-STD-1760 Munitions Instrument Suite.
Option 90-04
BRAT 90 Quick-Start Option 04 - Add a 7U Transportable Three Phase Power Supply with Facility Power Distribution and Signal Conditioning Unit.
Option 90-05
BRAT 90 Quick-Start Option 05 - Add a 5U Transportable case to facilitate reconfiguring, upgrading, and adding assets to option 90-03 and option 90-04 to facilitate automation for simultaneous ASI testing and loading. This option also converts the input power to 240 VAC universal single phase from three phase.
Option 90-10
BRAT 90 Option 90-10 - ETS Instrument Suite
Option 90-11
BRAT 90 Option 90-11 - ETS Panel Interface (4 NSIUs)
Option 90-12
BRAT 90 Option 90-12 - Transient Voltage Suppressor (TVS)/Data Acquisition Control (DAC) Testing Switch
Option 90-13
BRAT 90 Option 90-13 - Instrument Case and Interface modification moving cables and replacing mounting hardware to increase room for cable routing; includes securing hardware and brackets to move, mount, and fasten assemblies, switch boxes, and connectors.
BRAT 90, Option 02,03,04,05,12
